Product Line

OLED Displays

Self-emissive OLED display modules with infinite contrast, ultra-thin profiles, and wide viewing angles. Ideal for wearables, medical handhelds, and premium consumer devices.

Overview

Pure Blacks, Vibrant Pixels

Unlike LCDs which require a backlight, each OLED pixel emits its own light. The result: true blacks (pixel is off), infinite contrast ratio, 10μs response time, and a viewing angle that stays perfectly readable at 160°.

Self-emissive — no backlight needed, thinner and more power-efficient
Infinite contrast ratio with true blacks
Extreme temperature range: -40°C to +85°C
Available in white, blue, yellow, and color (RGB) variants

Request Samples

OLED display pixel structure macro close-up infinite contrast

Specifications

Technical Specifications

Display Technology	Passive Matrix OLED (PMOLED)
Available Sizes	0.42", 0.66", 0.91", 0.96", 1.3", 1.5", 2.23", 2.7"
Resolutions	72×40, 128×32, 128×64, 128×128
Color Options	White, Sky Blue, Yellow, Green (monochrome); RGB 65K color (select models)
Driver IC	SSD1306, SSD1309, SSD1327, SH1106, SH1107, SSD1357 (color)
Interface	I²C (default), 3/4-wire SPI
Contrast Ratio	>10,000:1
Response Time	≤10 μs
Viewing Angle	>160° (all directions)
Operating Temperature	-40°C to +85°C
Thickness	1.2mm (glass only), ~3mm (with PCB)
Supply Voltage	3.3V DC (logic), 7-15V (display boost)
