LCD20×4 Character LCD Module
HD44780-compatible, blue backlight, 5V operation, 98×60mm outline. Industry-standard character display for instrumentation and embedded systems.
- Resolution
- 20 chars × 4 lines
- Interface
- 4/8-bit Parallel
Product Catalog
Display Modules for Every Application
Browse our complete range. Filter by category, compare specifications, and request samples — all in one place.
LCD
LCD128×64 Graphic LCD Module
ST7920 controller, white LED backlight, 93×70mm. Ideal for data loggers, test equipment, and industrial HMI panels.
- Resolution
- 128 × 64 pixels
- Interface
- Parallel / SPI
OLED1.3" White OLED 128×64
SH1106 driver, I²C/SPI, ultra-thin 1.2mm glass, 160° viewing angle. Perfect for wearables and portable instrumentation.
- Resolution
- 128 × 64
- Interface
- I²C / SPI
OLED0.96" Blue OLED 128×64
SSD1306 driver, tiny 27×27mm outline, crisp blue emission. Extremely compact — ideal for key fobs, mini sensors, and IoT nodes.
- Resolution
- 128 × 64
- Interface
- I²C
Touch7.0" PCAP Touch Panel
Projected capacitive, multi-touch (5 points), 1.1mm chemically strengthened glass. Supports glove and water operation.
- Type
- PCAP Multi-touch
- Cover Glass
- 1.1mm CS Glass
Touch4.3" Resistive Touch Screen
4-wire analog resistive, 1.2mm film+glass, stylus and glove compatible. Cost-effective solution for industrial control panels.
- Type
- 4-Wire Resistive
- Activation
- Stylus / Glove
E-Paper2.9" E-Paper Display
296×128 resolution, SPI interface, bistable — zero power to retain image. Ideal for IoT labels and smart shelf tags.
- Resolution
- 296 × 128
- Power
- 0μW (static)
E-Paper4.2" Tri-Color E-Paper
400×300, black/white/red, SPI. Eye-catching red accents for retail signage and shelf labels.
- Resolution
- 400 × 300
- Colors
- B/W + Red
TFT7.0" TFT LCD 1024×600 IPS
IPS wide-angle, 1000 nit high-brightness, LVDS interface. With optional PCAP touch and optical bonding.
- Resolution
- 1024 × 600
- Brightness
- 1000 cd/m²
TFT10.2" TFT 1280×800 LVDS
Wide 16:10 aspect, IPS technology, 850 nit brightness. Ideal for medical monitors and industrial HMIs.
- Resolution
- 1280 × 800
- Brightness
- 850 cd/m²
No products found in this category.
Compare
Product Comparison
| Product | Category | Resolution | Interface | Brightness | Viewing Angle | Op. Temp |
|---|---|---|---|---|---|---|
| 20×4 LCD | LCD | 20×4 chars | Parallel | 250 cd/m² | 60°/60° | -20~70°C |
| 128×64 LCD | LCD | 128×64 | Parallel/SPI | 300 cd/m² | 70°/70° | -20~70°C |
| 1.3" OLED | OLED | 128×64 | I²C/SPI | 120 cd/m² | 160°/160° | -40~85°C |
| 0.96" OLED | OLED | 128×64 | I²C | 110 cd/m² | 160°/160° | -40~85°C |
| 2.9" E-Paper | E-Paper | 296×128 | SPI | N/A (reflective) | 180°/180° | 0~50°C |
| 4.2" E-Paper | E-Paper | 400×300 | SPI | N/A (reflective) | 180°/180° | 0~50°C |
| 7.0" TFT | TFT | 1024×600 | LVDS | 1000 cd/m² | 178°/178° | -20~70°C |
| 10.2" TFT | TFT | 1280×800 | LVDS | 850 cd/m² | 178°/178° | -20~70°C |
Custom Solutions
Don't See Exactly What You Need?
Most of our business is custom. We routinely modify existing designs — or create entirely new display modules — to match your exact specifications.
- Custom sizes, resolutions, and aspect ratios
- Tailored brightness, interface, and touch integration
- Cover glass printing, anti-glare, and anti-fingerprint coatings
- Full turnkey: design → prototype → validation → mass production
Ready to Order
Request Samples or a Production Quote
Tell us which products you're interested in and our team will prepare a detailed quotation with lead times.
